How to Create a Drawing Template in Solidworks 2018 TUTORIAL

SolidWorks: Custom Drawing Template

Custom Drawing Template

A cartoon template is one of the main components to any assembly or function cartoon. A drawing template allows you to convey all information nearly a part or associates in a clean and organized manner. The key features of a drawing template are simplicity and clarity. This blog will demonstrate how to make a uncomplicated custom drawing template in SolidWorks!

Opening A Drawing Sail

To create a custom cartoon template, a blank template is needed to start the cosmos. SolidWorks offers multiple different sizes and shapes of pre-made drawing templates inside the programs files. One of these pre-made templates will be open up and contradistinct to make it bare.  Click on the new certificate control on the toolbar at the height of the screen or under the file drop-down carte. After trying to open a new file, a pop-upwardly box will appear. Under the novice setting tab, there volition be 3 options: start a part, associates, or a cartoon. Choose the create new cartoon selection. Another pop-up window will announced with a listing of A-Due east drawing templates. These are SolidWorks default templates. Any size can be chosen but for this weblog, the A(ANSI) Landscape template will be modified. An image of how to go to the custom SolidWorks templates is shown beneath in Figure 1.

Figure-1-Custom solidworks templates location.PNG

Figure i: SolidWorks custom template location

Clearing the Format

In one case the pre-made template has been opened, the formatting needs to exist cleared to be able to input a new custom template. In the feature manager on the left, at that place will exist ii features, these are "Annotations", and "Sheet1". Click the driblet-downward arrow next to Sheet1 and some other feature volition announced called Sheet Format1. Correct click on Sheet Format1 and select delete, the drawing template will then plow blank. An image of how to clear the format is shown in Figure 2.


Figure ii: Immigration the canvas format

Editing the new canvass

At present that the sheet has been cleared, a new format can be created on information technology. In the drawing, select the Canvas Format tab located on the toolbar most the height of the screen. Select the Edit Sheet Format control on this tool tab. After this command is selected the other two commands on this tab will get available to use. Now, select the Automatic Edge command. The location of these commands are shown in Figure 3.


Effigy 3: Editing commands location

After the Automatic Border control is selected, the Property Manager will evidence a delete listing choice box. Since the format is already cleared, this step is not needed. The blue arrow at the top right of the property director can be clicked to move onto the adjacent step in the command. Afterward the blueish arrow is clicked, the property director will exist filled with multiple different options on how to arrange the border that is being previewed on the drawing sheet. The zones, margins, line size, and borders tin can all exist edited here. Once the desired sizes accept been called, click the green check mark at the tiptop of the property manager. At that place volition now be a border effectually the drawing template. The Automated Border holding manager is shown in Figure 4.


Figure four: Automatic Border belongings manager

Adding Sections

Now that the edge is finished, some sections for information need to exist added to help keep the template organized. To add together in sections, they just need to exist sketched in. Go over to the sketch tab and select the line or rectangle command. Create some boxes and proportion them to the size and shape that is desired for the custom template. An instance of the sections made for this blog is shown in Figure v.


Figure 5: Example added sections

After the sections have been added in they need to be labeled. This can exist done by placing annotations notes in each box. The Notation command tin can be found under the annotation tab on the toolbar nigh the top of the screen. A note is placed in each box of the title cake. This is done to give an input location for information about the drawing. Note size and shape can be adjusted past double-clicking on the note itself. An example of the layout for notes in a drawing template is shown in Effigy 6 beneath.


Figure 6: Example section labels

Finishing Touches

Notice that there is nevertheless a large empty space within championship block area. Typically, in this infinite or one like information technology, a decal belonging to either the person or the company is placed to evidence buying of the template. These pictures likewise help make the template await more aesthetically pleasing. For this blog example, the Perception Engineering science logo will be added. To add a picture to the template, the Edit Sail Format control must still be activated. If it is not, click on the command once more. Get to Tool on the toolbar at the very height of the screen and drop downwardly the carte du jour. Notice the Sketch Tools carte du jour and hit that drib-down carte as well. Nether the Sketch Tools menu, in that location volition exist a Sketch Movie control. After clicking this command simply select the desired picture from its file locations and information technology volition be placed onto the template. The picture can then be sized and edited in its Property Manager on the left-hand side. An example of this is shown in Effigy 7.


Figure seven: Sketch picture show case

Saving the New Template

Now that the new drawing template is consummate, it must be saved! To salvage this as a template to be used all that is needed is to save the file as a drawing template (*.drwdot) file. After it has been saved as a drawing, the file locations need to be edited to pull the template. Click on the gear at the top of the screen and select file locations in the carte on the left side of the pop-up menu. Under the "Bear witness folders for" drop-down menu, select Document Templates. All that is left to practise is select the folder that the drawing template was saved in and it can at present be pulled to utilize as a template someday! How to access the file locations is shown in Figure eight.


Figure 8: Editing the file locations

Terminal Thoughts

The purpose of a drawing template is to aid with organisation and presentation of a drawing and its information. A well-organized drawing template is a cinch way to portray professionalism when creating drawings. Even with just a simple template and title block such as the ane shown in this web log, the expect of a drawing tin be increased likewise as how easy information technology is to read and gather information.

If you would similar to learn more, check out these course that provide everything you need to know to go started!

Written Past:

Hayden Kemme

Hayden Kemme

CAD Designer at Perception Applied science
